PH6E0 - SLURRY/MUD SUCTION AND DISCHARGE HOSE W.P 10 BAR
Construction
Inner tube
Synthetic & natural rubber blend - black resistant to abrasion
Reinforcement
Two Plies of high tensile steel cords with steel helix
Cover
Synthetic rubber - black resistant to abrasion, weather, oil & ozone
Application
Heavy duty slurry hose designed for transporting abrasive & corrosive slurries in industries like waste cleaning trucks, dredging and wastewater treatment. They offer high abrasion resistance, flexible and durability ensuring efficient material handling in harsh environments.
| Item Code |
Dash Size |
ID
|
OD
|
WP
|
BP
|
BR/r
|
W
|
|||||
| inch | mm | inch | mm | psi | bar | psi | bar | inch | mm | kg/m | ||
| PH6E0-32 | -32 | 2 | 51.0 | 2.71 | 69.0 | 150 | 10 | 450 | 30 | 9.8 | 250 | 2.90 |
| PH6E0-48 | -48 | 3 | 76.0 | 3.74 | 95.0 | 150 | 10 | 450 | 30 | 15.7 | 400 | 4.10 |
| PH6E0-64 | -64 | 4 | 102.0 | 4.80 | 122.0 | 150 | 10 | 450 | 30 | 21.7 | 550 | 5.60 |
| PH6E0-80 | -80 | 5 | 127.0 | 5.82 | 148.0 | 150 | 10 | 450 | 30 | 25.6 | 650 | 8.40 |
| PH6E0-96 | -96 | 6 | 152.0 | 6.88 | 175.0 | 150 | 10 | 450 | 30 | 29.5 | 750 | 10.10 |
Temperature Range : -30°C to +70°C
