PH440 - COMPRESSED AIR WIRE BRAIDED HOSE
Construction
Inner tube
Black colour, Synthetic rubber resistant to air
Reinforcement
Single steel wire braid
Cover
Yellow colour, Synthetic rubber resistant to water. Also available in Black cover on request
Application
Compressed air service in severe working conditions in mines, quarries and industrial applications
| Item Code |
Dash Size |
DN |
ID
|
OD
|
WP
|
BP
|
BR/r
|
W
|
|||||
| inch | mm | inch | mm | psi | bar | psi | bar | inch | mm | kg/m | |||
| PH440-08 | -08 | 12 | 1/2 | 13.1 | 0.79 | 20.0 | 580 | 40 | 1740 | 120 | 7.9 | 200 | 0.365 |
| PH440-12 | -12 | 19 | 3/4 | 19.3 | 1.06 | 27.0 | 580 | 40 | 1740 | 120 | 9.4 | 240 | 0.520 |
| PH440-16 | -16 | 25 | 1 | 25.9 | 1.40 | 35.5 | 580 | 40 | 1740 | 120 | 11.8 | 300 | 0.821 |
| PH440-20 | -20 | 32 | 1.1/4 | 32.4 | 1.65 | 42.0 | 580 | 40 | 1740 | 120 | 16.5 | 420 | 1.114 |
| PH440-24 | -24 | 38 | 1.1/2 | 38.7 | 2.04 | 51.7 | 580 | 40 | 1740 | 120 | 19.7 | 500 | 1.529 |
| PH440-32 | -32 | 51 | 2 | 51.3 | 2.48 | 63.0 | 580 | 40 | 1740 | 120 | 24.8 | 630 | 2.058 |
| PH440-40 | -40 | 63 | 2.1/2 | 63.5 | 3.15 | 80.0 | 580 | 40 | 1740 | 120 | 30.0 | 762 | 4.196 |
| PH440-48 | -48 | 76 | 3 | 76.2 | 3.74 | 95.0 | 580 | 40 | 1740 | 120 | 36.0 | 915 | 5.394 |
| PH440-64 | -64 | 100 | 4 | 101.6 | 4.67 | 118.5 | 580 | 40 | 1740 | 120 | 48.0 | 1220 | 6.110 |
Temperature Range : Continuous: -40°C to +90°C
